Advantage:
This control board single 4 military grade PCB Board, covered in
gold, Tin, avoiding cold solder joint. High quality HDMI interface,
ARM processors, imported foreign brand chips and capacitors
resistors and other electronic components
Description:
This HDMI Board of SONY HD movement, is a designed for SONY FCB HD
integration module research and design, and is compatible with SONY
FCB-EH3410,FCB-EH3310,FCB-EH3150,FCB-EH6300,FCB-EH6500,FCB-EV7500,FCB-EV5500,FCB-EV7100,FCB-EV7300
, FCB-EV7310,FCB-EV5300 and so on. This widely used control panels,
can be applied to aerial photography, amblyopia, and video
conferences, medical devices or other specialized equipment.
Specification:
1.access through LVDS line SONY FCB HD integrated core modules
without any settings to the movement, it can automatically identify
displays HD signals.
2.Through five-way key, or 485 control keyboard to bring up the OSD
menu, easy to set the technical parameters of the core module and
save the parameter value.
3.Support RS485 control, automatic identification of
PELCO-D,PELCO-P agreement, Potter is 2400bps,4800bps,9600bps, add
is 1--255. .
4.Support power off memory function, when a camera module parameter
setting saved, after the power of the camera module, no need to set
the parameters of the camera module.
5.Unique video formats change, who cannot see the image display,
video format can be changed to 720P50,1080/50,1080P50/P60, 485
remote control keyboard can also be changing the video format.
6. Unique 10 presets and auto cruise function, cruising time of
5----999 seconds. (Optional).
7.Support for SONY, VISCA Protocol of camera module.
8. Size:48MM*48MM*15MM
