Product features:
* Full HD (1920 x 1080, 30 FPS), HD (1280 x 720, 60 FPS)
* Minimum illumination: colour: 1.5 lx Lux @ F1.6 (50 IRE);Black
and white: 0.1 Lux @ F1.6 (50 IRE);
* Night of ICR conversion, intelligent video .
* Dynamic detection, the privacy shelter, SSNR (3 D + 2 D)
Video:
* Image: 1/3" progressive scanning CMOS.
* The total pixels: 2010 (H) x 1108 (V), 2.2 M pixels
* Effective pixels: 1944 (H) x 1092 (V), 2.1 M pixels
* Scanning system: progressive scan
* Frame rate: 30 FPS (1920 x 1080)
* Minimum illumination: color: 1.5 lx Lux @ F1.6 (50 IRE) black and
white: 0.1 Lux @ F1.6 (50 IRE)
* Signal to noise ratio: 50 db
* Video output :Through an LVDS digital output Y/Cb/Cr 4:2:2 ,
HDanalog output Y/Pb/Pr , monitoring CVBS
Lens type:
* The focal length (zoom ratio): 4.45 ~ 89 mm (20 x optics)
* The largest aperture ratio: 1:1. 6 (Wide) to 2.9 (Tele)
* Angle of view: H: 56.56 ˚ (Wide) ~ 3.10 ˚ (Tele) / V: 43.32 ˚
(Wide) ~ 2.34 ˚ (Tele)
* Minimum distance: Wide 50mm ,Tele 1m
* Focus control: Automatic/manual focus control/at once
* Zoom movement speed: 3.3 seconds (fast), 5.8 seconds
(intermediate), 7.4 seconds (slow)
The operating:
* Screen shows: South Korea, Japan, in English, law, Germany, the
west, Italy, Russia,turkey
Portugal .
* Camera name: close/open (display 15 characters)
* Day & Night Convert: automatically (ICR)/color/black and white
* Backlight compensation: Close/backlight compensation/light
inhibition
Wide Dynamic Range
* Dark space compensation: SSDR - level is adjustable
* Digital noise reduction: SSNR Ⅲ (off/low/medium/high)
* Digital image stabilization: close/open
* Privacy shelter: close/open (eight rectangle, one polygon)
* Iso (the accumulated frame): accumulation auto/off (optional
limit ~ 60 x)
* Gain control: High/medium/low/manual gain control
* White balance: ATW/indoor/outdoor/AWC/manual
* Electronic Shutter : Esc/A.F LK/manual
* Digital zoom: close/open (1 ~ 16 x x)
* Flip/mirror: Close/H - Rev/V - Rev/HV - Rev
* Intelligent Video Analysis: Fixed _ mobile, dynamic detection,
tracking, fences, counting, and sabotage
* Communication: RS - 232C
The environment:
* Work Temperature/humidity: - 10 ° C ~ + 50 ° C (+ 14 °F ~ 122 °
F) / < 90% RH
Electronic:
* The input voltage/current: 12 VDC± 10%
* Power consumption: Biggest 4.72 W
The appearance characteristics:
* Size (width x height x deep): 48.6 x 53.8 x 93.7 mm
* Weight: 213 G
